Product Overview

The TC-PCIC01 REV E01 FW 3.5 is a ControlNet interface card designed to connect HC900 controllers or servers to a Honeywell ControlNet network for distributed control and data exchange.

This PCI-based card enables HC900 systems to communicate with other ControlNet nodes including remote I/O racks, controllers, and operator stations in real-time.

Key Features & Specifications

• ControlNet protocol: Full implementation for deterministic real-time communication with sub-millisecond response.
• Interface: PCI or PCIe form factor for integration into computers and HC900 systems.
• Network speed: 5 Mbps ControlNet bandwidth supporting multiple I/O modules and peer controllers.
• Node addressing: Configurable ControlNet address (0–63) for unique network identification.
• Connector type: Industrial-grade circular or terminal-block connectors for field installation.
• Firmware updateable: Supports updates for compatibility and bug fixes.
• Redundancy ready: Compatible with redundant network paths when used with switching infrastructure.

Typical Applications / Use Cases

ControlNet interface cards enable real-time communication in HC900 systems requiring distributed I/O or multiple controllers.

• Connecting HC900 controllers to remote I/O racks, eliminating long individual signal cable runs.
• Linking multiple HC900 systems for coordinated control strategies with real-time data sharing.
• Integrating HC900 systems with Honeywell or third-party SCADA supporting ControlNet.
• Supporting machine-to-machine communication in manufacturing with synchronized multi-station control.

Advantages / Why It Matters

• Deterministic communication: Sub-millisecond cycle time ensures precise timing for synchronized tasks.
• Reduced wiring: Network eliminates individual signal cables, reducing labor and panel space.
• Scalable architecture: Supports 64 nodes per segment for flexible HC900 expansion.
• Industrial resilience: EMI filtering and shielding for noisy factory environments.
